Kool-Ray Pillar Mounting Spindle Jig

The Mounting Spindle Jig is the install tool that speeds up Kool-Ray Pillar railing assembly. The jig holds spindles at exactly the code-compliant centre-to-centre spacing (≤4") while you fasten them to the top and bottom rails — no measuring, no marking, no math on site.

What it does

• Holds multiple spindles at correct ≤4" CC spacing simultaneously
• Eliminates per-spindle measurement and layout
• Cuts assembly time on custom-cut sections by ~50%
• Guarantees code compliance — no chance of misspacing on a custom job

Who needs this

• Contractors doing multiple Pillar railing installs per season
• Pros who frequently custom-cut sections (non-standard spans)
• DIYers tackling more than ~30 linear feet of Pillar railing

Pre-assembled factory sections don't require the jig — only custom-cut work and field repairs.

Warranty

Imperial Kool-Ray 20-year limited transferable warranty.
